CNC Chomutov - Sedláček Jan

Tel.: 603 245 778, Mail: jan.sedlacek@seznam.cz, Web: www.cnc-chomutov.cz


CNC Chomutov s.r.o.

We offer services in the field of precision engineering - cnc turning and CNC milling.

We work with brass, nylon (plastic), aluminum and steel solid rods and tubes, cast aluminum and cast iron. We supply products with surface treatment - anodizing, painting, galvanizing, etc. - according to customer



Company focus - especially on smaller series production from 100 to 5000pcs monthly of individual products.

All production materials have a quality certificate.



Shipping: Finished products are delivered directly to the customer in the desired packaging





Company machinery:



  •  Horizontal CNC turning machine - Lynx 220 LB
Horizontální soustruh CNC - Lynx 220 LB Parameter
Value

Number of directed axis

Operating system Fanuc

2
Max. bar working diameter - mm 51
Max. turning lengh- mm  525
Max. turning diameter- mm 320
Travel distance axis - mm 510
Spindle - speed / minute 5000
Engine - power in kW 15
Number of tools 12
  • Horizontal CNC turning machine  - PUMA 240 MB
Parameter
Value

Number of directed axis

Operating system Fanuc

Max. bar working diameter  - mm 65
Max. turning lengh- mm 513
Max. turning diameter- mm 300
Travel distance axis - mm  550
Spindle - speed / minute 4500
Engine - power in kW  18,5
Number of tools  12
  •  Vertical milling centre  SUMO 610
  Parameter
Value

Number of directed axis

Operating system

Heidenhain

 3
Max. rapid traverse X/Y/Z 610/480/510
Worktable size in mm 800x450
Spindle nose to table surface - mm 140-650
Spindle centre to - stand-mm

520

Spindle - speed / minute 12000
Engine- power in kW 11
Number of tools 24
